Selected Dimensions

DIMENSIONS
A. Overall Length: 33.1 ft
B. Overall Width: 8.2 ft
C. Overall Height – Mast Lowered: 8.9 ft
D. Wheelbase: 9.8 ft
E. Ground Clearance: 13 in

PLATFORM
F. Max Platform Height: 65.9 ft
G. Max Horizontal Reach: 56.1 ft

Specifications

ENGINE
Fuel Type: Diesel

OPERATIONAL
Operating Weight: 25000.4 lbs
Max Speed: 3 mph
Tire Size: 15×19.5

PLATFORM
Max Platform Height: 65.9 ft
Max Horizontal Reach: 56.1 ft
Max Platform Weight Capacity: 500.4 lbs
Platform Length: 59.8 in
Platform Width: 29.9 in
Manufacturer Manual: Download PDF
