Selected Dimensions

DIMENSIONS
A. Overall Length: 42.7 ft
B. Overall Width: 8.5 ft
C. Overall Height – Mast Lowered: 10.2 ft
D. Wheelbase: 12 ft

PLATFORM
F. Max Platform Height: 126 ft
G. Max Horizontal Reach: 63 ft

Specifications

ENGINE
Fuel Type: Diesel

OPERATIONAL
Operating Weight: 41839.3 lbs
Max Speed: 3 mph
Tire Size: 15×22.5

PLATFORM
Max Platform Height: 126 ft
Max Horizontal Reach: 63 ft
Max Platform Weight Capacity: 500.4 lbs
Platform Length: 96.1 in
Platform Width: 29.9 in
