Selected Dimensions

DIMENSIONS
A. Overall Length: 42.3ft
B. Overall Width: 8.6 ft
C. Overall Height – Mast Lowered: 9.6 ft
D. Wheelbase: 13 ft

PLATFORM
F. Max Platform Height: 86 ft
G. Max Horizontal Reach: 78.3 ft

Specifications

ENGINE
Fuel Type: Diesel

OPERATIONAL
Operating Weight: 38,690 lbs
Max Speed: 3 mph
Tire Size: 15×625 foam filled lug

PLATFORM
Max Platform Height: 86 ft
Max Horizontal Reach: 78.3 ft
Max Platform Weight Capacity: 500 lbs
Platform Size: 8ft x 3ft
